Standard BRIDGE Data Pipeline

alt text Example pipeline for imaginary "Device_X" which is a BLE Input Device used in an example Visualizer Page

Frontend (App) side​

(See System Architecture for more details)

Device and Data Context:​

  • Device and Data Context (See ...)

This essential component will contain a reference to all active devices being used by the app.

info

Think of the DDC as the hub through which all components of the app talk to devices through.

Hooks:​

info

Hooks are effectivley complex functions we can pass around to access and store information.

  • useDeviceStream: Returns a reference to device data when provided with a device reference
  • useConnectionState: Returns a reference to the connection state of a device, useful for dynamic connection indicators and error handling.

Also...

  • useDeviceScanner: Handles the scanning for bluetooth device logic. If you select a BLEInputDevice type for example, this hook is used to scan and filter for that specific device.

Pages:​

Assume you have connected via the standard Connections Page. See Pages for more details.

When using the Connections Page, you will typically add a device.

info

Available devices are always defined using the Device Registry. This is a separate component to the Device-and-Data-Context.

Example Page:

  • Visualizer Page: Listens to an active device stream and visualizes its data, updating every 16 ms.

Backend side​

The backend runs outside of the React ecosystem. This allows us to more intuitively control and interact with them at a higher level while allowing some degree of abstraction between components (example: Calling Device.connect() instead of complex custom connection logic in every page for every device...)

Devices​

Devices all have standard behavior, defined by the root-level Base Device class. (See System Architecture: Base Device)

We have several device sub-types defined, they inherit properties from Base Device, but expand on them with some unique functionality. (See beneath System Architecture: Base Device)

info

In the example pipeline shown, a device, "Device_X" extends the System Architecture: BLE Input Device which itself extends System Architecture: Base Device.
